Opel 3 Plus

Vendor RSF
Call for Pricing
This is a pre order item. We will ship it when it comes in stock.

Call us : (905) 615-0880



The Opel Plus series has taken the Opel family of catalytic fireplaces to the next level.

EPA certified at 0.7g/hr makes the Opel Plus one of the most advanced and cleanest units available on the market today, yet it still maintains its classic styling. In the past, Popular Science Magazine has recommended the Opel for its efficiency and reduction of emissions. Over the years this technology has only improved and been refined to make the Opel Plus what it is today.

Catalyst Care Tips:

  • Burn natural wood only. Do not burn chemical chimney cleaners, chemically treated wood, driftwood, construction scrap or garbage in your unit.
  • Purchase the optional Digital Temperature Display (FO-DTD) to monitor the temperature of your catalyst.
  • Maintain a healthy catalyst temperature between 175°C (350°F) and 700°C (1300°F). Prolonged high or low temperatures may shorten the life of your Opel catalyst.
  • Remove cooled ash from the face of the catalyst by brushing it gently with a soft bristle brush (e.g. paint brush). Vacuum use near the face of the catalyst to remove the remaining ash is permitted; however avoid direct contact with the catalyst unit.
  • Limit cleaning to the visible face of the catalyst only. Attempting to clean the individual catalyst openings may do more harm than good. Scrapers or hard bristle brushes are never recommended.

THE RSF COMFORT ADVANTAGE

Comfort is our specialty. We customize heat distribution from a wood fireplace throughout the home, including the basement. When the household temperature is tailored for a family at minimal cost and maximum efficiency, we call that the RSF Comfort Advantage.

Note: the central heating option is not available for the Pearl 3600, the Focus 3600 or Focus ST.



AVAILABLE OPTIONS

Opel 3 decorative Trim

This kit allows you to add a nice decorative trim to your Opel3 door. Whether it is black, gold plated or pewter plated, the decorative trim is easy to install and remove.

Louvers for the Opel

There are many ways you can finish your OPEL C1 fireplace. You can choose to install louvers – with or without the upper louver – louvers are available in various styles (regular black: FO-OPLB; or decorative black (FO-OPLC) or no louvers at all (FO-F3).

DOWNLOAD

Opel Louver Trim

The Opel Louver Trim is a portrait style frame to cover the rough-cut edges of finishing around the opening of the upper louver on an Opel fireplace. It is not intended for use with heavy or thick finishing’s.

DOWNLOAD

Gravity Vent Kit

The gravity vent kit uses natural convection to distribute the heat generated by the fireplace to the same floor and/or floors above the fireplace.

DOWNLOAD

Clean Face
FO-F3 + FO-V2/V3 (x2)

The Clean Face Kit is required on all complete clean-face installations. It consists of blocking plates that cover the grill openings and an air intake duct that brings air circulating in the home into the fireplace. Gravity vents are required with this option.

DOWNLOAD

Gravity Vent Kit – Rectangular

The gravity vent kit uses natural convection to distribute the heat generated by the fireplace to the same floor and/or floors above the fireplace.

DOWNLOAD

Internal Blower

The internal blower kit will increase the circulation of heated air in the room where the fireplace is installed.

DOWNLOAD

Central Heat Blower Kit

The central heat blower kit enables the distribution of heat generated by the fireplace throughout many rooms and different floors using either dedicated ducts or the house central heating ducts.

DOWNLOAD

Gravity Vent Damper

The Gravity Vent Damper can be installed on a louvered fireplace to add some control to the Gravity Vent (FO-V2).

DOWNLOAD

Central Heating Tee

This Tee allows you to have two Gravity Vents (FO-V2) on your fireplace and still be able to install the Central Heat option (FO-FDHB6-1).

DOWNLOAD

Heat Dump

The Heat Dump Kit contains all the parts necessary to circulate a moderate amount of heat from your fireplace to another room with a small fan.

DOWNLOAD

Masonry Chimney Adapter

This adapter will attach to the liner with 3 stainless steel rivets (provided) and to the EXCEL chimney with 3 screws (provided).

Rock Retainer Kit (Opel)

This rock retainer kit will allow you to finish your Opel fireplace with thin non-supporting facing such as tiles.

DOWNLOAD


Door Gasket Replacement Kit3/4’’

This kit (FO-GRK4) includes the gasket and high temperature sealant required to change the door gasket on your fireplace.

DOWNLOAD

DOCUMENTS AND SPECS

Note: The installation manual should always be used for the precise planning and accurate installation of your fireplace.

GENERAL SPECIFICATIONS
Outside Dimensions 37″ W X 52 1/4″ H X 24″ D
Shipping weight 553 lb
Glass viewing size 22 ¼” W x 14 9/16″ H
Firebox Size

The observable firebox volume is 3.6 cubic feet

EPA official usable firebox volume per certification testing is 2.3 cubic feet.

Firewood Length EPA tested with 15.75″ logs; can accept up to 18″ logs
Chimney 7″ Excel
Door Finish Black Single Door
Outside Air

4″, meets R2000

All RSF models come equipped to accept a 4″ outside air duct, a 5″ can also be used. All models can also be installed to operate using room air.

Mobile Home Approved NO
PERFORMANCE
BTU Output

27,034 BTU/hr

Based on EPA certification testing using crib wood and calculations from CSA B415.1-10.

Estimated BTU Potential

70,000 BTU/hr

Based on engineering calculations using firebox volume, efficiency, loading density (12lb/cu ft for hardwood), average humidity, reloading interval, type of installation, etc.

Heating Capacity

1,500 to 3,000 ft2

Depends primarily on wood quality, ambient air temperature and building heat loss.

EPA Certification 0.7 g/hr
Optimal Efficiency

80%

Low Heating Value (LHV) CSA B415.1-10 calculations.

EPA Average Efficiency

70%

High Heating Value (HHV) CSA B415.1-10 calculations.

EPA Average CO

.58 g/min

Carbon Monoxide (CO), using data from EPA crib wood testing
